Serial No.69381
Year of Manufacture 2005
Control HAAS
Turning length 20" / 508mm
Turning diameter 10.1/4" / 260mm
Swing over Covers 23" / 584mm
Between centres 24" / 610mm
Swing over cross slide 9.1/2" / 241mm
Spindle speeds Up to 4000 rpm
Bar capacity 2" / 51mm
Number of stations on turret 10
Spindle bore 3" / 76mm
Tail stock Yes
Feed rate Up to 710" / 18,034mm per Minute
Input 415/3/50 ac 20 hp
3 jaw chuck 210mm Diameter
Fitted with Swarf Screw & Tool Presetter
Length 9' / 2.74m
Width 6' / 1.83m
Height 5'10" / 1.78m
Nett weight approx. 4 ton / 4064 kgs
Turning length 20" / 508mm
Turning diameter 10.1/4" / 260mm
Swing over Covers 23" / 584mm
Between centres 24" / 610mm
Swing over cross slide 9.1/2" / 241mm
Product Code: C470A1M
Brand: Haas
Product Condition: Used
weight: 4064.0kg
